BUTYL RUBBER SHEETS & ROLLS |
|
|
. |
|
DESCRIPTION : |
|
Butyl Rubber sheet
/ roll is a very low permeability to air & other
gases. These sheets have excellent resistance to
sunlight, ozone & oxidation. The operating
temperature resistivity ranges from (-30°C to
+110°C). It is resistant to most inorganic
products and best resistance to mineral acids &
alkaline.
|
|
APPLICATIONS : |
|
These sheets / rolls are used for Chemical tank
lining, Pharmaceutical stoppers, Acid protective
clothing & many more applications.
|
|
PROPERTY : |
|
Very good resistance to acids & alkalis. Very
good for low resilience applications like shock
absorber & vibration dampers. Not recommended
its use in applications where resistance to oils
& hydrocarbons is required.
|
|
 |
|
PHOTO GALLERY |
|
|
CATALOG |
GRADES |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb
(%) |
|
 |
BIIR-12560 |
1.2 |
55 |
80 |
350 |
|
|
BIIR-13065 |
1.3 |
60 |
60 |
300 |
|
|
BINR-60
(IIR : NR =
60:40) |
1.3 |
65 |
70 |
350 |
|
|
|
|
PRODUCT DIMENSIONS |
|
Rotocure Finish |
|
Plate Finish |
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 10, 20,
30 |
3 to 12 |
|
Finish |
Smooth /
Texture Impression |
|
|
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 2.4 |
3 to 25 |
|
1.0 x 2.0 |
3 to 25 |
|
|
|
|
|
|
MANUFACTURING TOLERANCES |
|
THICKNESS |
WIDTH |
LENGTH |
HARDNESS |
DENSITY |
|
+ / -
0.3mm or 10% whichever is higher |
+ / - 2% |
+ / - 5% |
+ / - 5 |
+ / - 0.05 |
|
|
|
|
RECOMMENDATIONS REGARDING STORAGE AFTER RECEIPT |
|
Store
according to DIN 7716 standards. |
|
Products must
be stored in cool, dry & dark places with temperature ranging between
10°C to 30°C, sheltered from the sun & free from ozone for better shelf
life. |
|
Avoid contact
with hydrocarbons, solvents. |
|
If there is
any doubt about the condition of sheet/roll, they should be retested
before putting into service. |
|
Products
should be issued in the order of their date of manufacture. |
|
|
|
