NITRILE RUBBER SHEETS & ROLLS |
|
|
. |
|
DESCRIPTION : |
|
Nitrile Rubber is a
copolymer of butadiene and acrylonitrile.
Nitrile rubber sheets are mainly used as oil &
solvent resistance as it has good tensile
strength, low compression set, flexibility &
impermeability to gases. These sheets are very
good resistance to petroleum based products
having recommended for operating temperature
from (-20°C to +110°C).
|
|
APPLICATIONS : |
|
These sheets /
rolls are mainly used for sealing, gasket &
packing to avoid leakages from oil, solvent,
petroleum based fluids, lubricating oil,
transformer fluid & sealing against gases..
|
|
PROPERTY : |
|
Very good
resistance to petroleum based fluid goods & high
temperature resistance up to 110°C.
Very
low-level permeability to gases.
Poor ozone resistance.
|
|
 |
|
|
 |
|
PHOTO GALLERY |
|
|
100%
NITRILE RUBBER SHEET : BLACK |
|
CATALOG |
GRADES |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb
(%) |
|
 |
BNT-1240 |
1.2 |
40 |
60 |
500 |
|
|
BNT-1350 |
1.3 |
50 |
70 |
450 |
|
|
BNT-1460 |
1.4 |
60 |
80 |
400 |
|
|
BNT-1570 |
1.5 |
70 |
80 |
300 |
|
|
|
|
COMMERCIAL
GRADE NITRILE RUBBER SHEET |
|
CATALOG |
GRADES |
NEOPRENE (%) |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb(%) |
|
|
BNTNR-50 |
50 |
1.6 |
65 |
20 |
250 |
|
|
|
|
PRODUCT DIMENSIONS |
|
Rotocure Finish |
|
Plate Finish |
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 10, 20,
30 |
3 to 12 |
|
Finish |
Smooth /
Texture Impression |
|
|
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 2.4 |
3 to 25 |
|
1.0 x 2.0 |
3 to 25 |
|
|
|
|
|
|
MANUFACTURING TOLERANCES |
|
THICKNESS |
WIDTH |
LENGTH |
HARDNESS |
DENSITY |
|
+ / - 0.3mm or
10% whichever is higher |
+ / - 2% |
+ / - 5% |
+ / - 5 |
+ / - 0.05 |
|
|
|
|
RECOMMENDATIONS REGARDING STORAGE AFTER RECEIPT |
|
Store
according to DIN 7716 standards. |
|
Products must
be stored in cool, dry places with temperature ranging between 10°C to
30°C, sheltered from the sun & free from ozone for better shelf life. |
|
Avoid contact
with acids & alkalies. |
|
If there
is any doubt about the condition of sheet/roll, they should be retested
before putting into service. |
|
Products
should be issued in the order of their date of manufacture. |
|
|
|
