NEOPRENE RUBBER SHEETS & ROLLS |
|
|
. |
|
DESCRIPTION : |
|
Neoprene rubber is a chloroprene rubber, which
has excellent mechanical property & good
abrasion resistance. It gives good resistance to
oil & heat, ozone, sunlight & weather and also
gives good adhesion to metal surface. Neoprene
rubber sheets / rolls are available for a range
of applications in the industries. Many grades
of neoprene are available depending on the
application. These rolls will handle most tough
industrial environments and moderate to heavy
alkaline and chemical resistive situations. It
is manufactured in pure neoprene rolls,
commercial, Medium strength, High Strength,
Cloth Inserted, Antistatic, Fire Retardant, and
Textured & in Strips. The temperature ranges
from (-30°C to +100°C) in operation condition.
|
|
APPLICATIONS : |
|
Neoprene rubber
sheets / rolls are mainly used in sealing
applications in construction sites & sound
studios, general & industrial applications like
sealing, gasket & packing to avoid leakages of
oil, heat, steam, water, air, acid & alkali. It
is also used in marine applications. It has
flame retardant properties & good resistance to
inorganic chemical products.
|
|
 |
|
. |
 |
|
PHOTO GALLERY |
|
|
100%
NEOPRENE RUBBER SHEET : BLACK |
|
CATALOG |
GRADES |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb(%) |
|
 |
BNP-1445 |
1.4 |
45 |
60 |
350 |
|
|
BNP-1555 |
1.5 |
55 |
70 |
300 |
|
|
BNP-1665 |
1.6 |
65 |
70 |
250 |
|
|
|
|
COMMERCIAL GRADE NEOPRENE RUBBER SHEET |
|
. |
|
DESCRIPTION : |
|
Commercial Grade Neoprene rubber blended with
natural rubber is a general-purpose sheet for
most commercial applications. This grade of
rubber is used as a barrier or gasket material
and can also be used inside rooms for
sandblasting and impact resistance for
industrial needs. Commercial Grade Neoprene
rubber sheet / roll are moderately resistance to
oil, sunlight, ozone and oxidation material
providing abrasion resistance, repeated flexing
applications, wide temperature range (excellent
cold temperature flexibility) and has a physical
toughness.
|
|
APPLICATIONS : |
|
Wear resistant
pads, vibration pads, isolation mounts, buffers,
diaphragms, industrial matting, water retaining
structures and in industrial applications such
as gaskets, corrosion-resistant coatings. For
more information click here.
|
|
 |
|
PHOTO GALLERY |
|
|
|
|
|
COMMERCIAL
GRADE NEOPRENE RUBBER SHEET |
|
CATALOG |
GRADES |
NEOPRENE (%) |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb(%) |
|
|
BNPNR-15 |
15 |
1.65 |
65 |
20 |
150 |
|
|
BNPNR-30 |
30 |
1.60 |
65 |
30 |
200 |
|
|
BNPNR-50 |
50 |
1.55 |
65 |
40 |
200 |
|
|
BNPNR-70 |
70 |
1.50 |
65 |
50 |
250 |
|
|
|
|
PROPERTY : |
|
General
purpose sheets / rolls resist moderate oil & heat resistance, fungus
resistance, flame retardancy, acid & alkali resistance, sunlight aging &
heat resistance up to 100°C. Best quality for sealing gasket, packing,
mounting pad, machinery packing, manhole packing, as a mechanical
applications without confect any fuel & also useful in marine parts due
to good ozone resistance. |
|
|
|
|
PRODUCT DIMENSIONS |
|
Rotocure Finish |
|
Plate Finish |
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 10, 20,
30 |
3 to 12 |
|
Finish |
Smooth /
Texture Impression |
|
|
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 2.4 |
3 to 25 |
|
1.0 x 2.0 |
3 to 25 |
|
|
|
|
|
|
MANUFACTURING TOLERANCES |
|
THICKNESS |
WIDTH |
LENGTH |
HARDNESS |
DENSITY |
|
+ / - 0.3mm or
10% whichever is higher |
+ / - 2% |
+ / - 5% |
+ / - 5 |
+ / - 0.05 |
|
|
|
|
RECOMMENDATIONS REGARDING STORAGE AFTER RECEIPT |
|
Store
according to DIN 7716 standards. |
|
Products must
be stored in cool, dry places with temperature ranging between 10°C to
30°C, sheltered from the sun & free from ozone for better shelf life. |
|
Avoid contact
with hydrocarbons, solvents, acids & alkalies. |
|
To maintain
the sheet/roll in optimum condition they should be stored in cool and
dark place. If there is any doubt about the condition of sheet/roll,
they should be retested before putting into service. |
|
Products
should be issued in the order of their date of manufacture. |
|
|
|
