DIAPHRAGM RUBBER SHEETS & ROLLS |
|
|
. |
|
DESCRIPTION : |
|
Diaphragm Rubber sheets are manufactured by
inserting 1 ply & 2 ply Nylon Fabric used as
Diaphragms for wide variety of applications
specifically for Oil, LPG & solvent resistant
applications. Recommended use for control
valves, regulators, pumps etc. Diaphragm sheet
is manufactured with high quality Nitrile rubber
compound designed for long service. This rubber
sheet is reinforced with multi-ply fabric to
provide desired strength. The purpose of
providing insertion is to provide additional
strength to material in order to make it more
pressure proof. Selection of fabric is available
on request.
|
|
 |
|
PHOTO GALLERY |
|
|
CATALOG |
GRADES |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb
(%) |
|
 |
BDR-1370 |
1.3 |
70 |
80 |
300 |
|
|
|
|
PRODUCT DIMENSIONS |
|
Rotocure Finish |
|
Plate Finish |
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 10, 20,
30 |
3 to 12 |
|
Finish |
Smooth /
Texture Impression |
|
|
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 2.4 |
3 to 25 |
|
1.0 x 2.0 |
3 to 25 |
|
|
|
|
|
|
MANUFACTURING TOLERANCES |
|
THICKNESS |
WIDTH |
LENGTH |
HARDNESS |
DENSITY |
|
+ / -
0.3mm or 10% whichever is higher |
+ / - 2% |
+ / - 5% |
+ / - 5 |
+ / - 0.05 |
|
|
|
|
RECOMMENDATIONS REGARDING STORAGE AFTER RECEIPT |
|
Store
according to DIN 7716 standards. |
|
Products must
be stored in cool, dry & dark places with temperature ranging between
10°C to 30°C, sheltered from the sun & free from ozone for better shelf
life. |
|
Avoid contact
with acids & alkalies. |
|
If there is
any doubt about the condition of sheet/roll, they should be retested
before putting into service. |
|
Products
should be issued in the order of their date of manufacture. |
|
|
|
